*Channel Height :100mm
Details View
• Excellent Waterproof of IP68
• Low power consumption, 80% energy saving
• apply to the low channel by optic lens use
• Excellent Stability
• Very Easy Installation
Application
Large channel letter lighting, Commercial standing, Light box, flex faced, cabinet...
Specification
|
Color |
WHITE |
RED |
GREEN |
BLUE |
|
Operating Power |
DC12V |
|||
|
LED CHIP PKG |
Samsung 5630 pkg |
Domestic |
||
|
Power / Current Dissipation |
1W |
0,72W |
||
|
LED Spec |
160° view angle, 50 000hr rated life, made in korea |
|||
|
Luminous Flux (lm/piece) |
100 |
17,8 |
30,5 |
6,8 |
|
Luminous Efficiency (lm/W) |
75 |
24,7 |
42,4 |
9,4 |
|
Dominent wavelength |
- |
625 |
525 |
460 |
|
Standard color temperature (K) |
10 000 |
- |
- |
- |
|
Module connection & cuttability |
wire to wire series connection, every module |
|||
|
Recommended channel height |
Min. 40mm |
|||
|
Dimension |
15mm(W)*71mm(L)*10mm(H) |
|||
|
Wire length |
90mm |
|||
|
Piece weight |
8.3g |
|||
| Operating Temperature | 20°C∼60°C | |||
| Storage Temperature |
30°C∼70°C |
|||
|
Waterproof rate |
IP68 |
|||
|
Cable |
AWG18 |
|||
| Case Material |
ABS housing |
|||
|
CRI (color rendering index) |
≥70Ra | |||
|
Working hours |
50 000hr |
|||
